PET Bottle Mould Design India — Ultra Mould Custom Engineering

Ultra Mould (Pratham Engineering) offers complete PET bottle mould design services in India — from initial bottle concept to final mould engineering and production. Whether you have a finished 3D CAD file ready or just a rough sketch of the bottle shape you want, our engineering team converts your requirement into a precision CNC-machined blow mould optimised for your Indian machine and production targets.

Good PET bottle mould design is the foundation of consistent bottle quality. Wall thickness distribution, blow ratio, preform compatibility, cooling channel placement, and parting line position — all these design decisions directly affect your bottle quality, cycle time, and mould life. Ultra Mould's engineers bring 10+ years of Indian market experience to every design.

Water Bottle Mould Design — Most Popular Specifications

The water bottle mould design is Ultra Mould's highest-volume segment. Indian mineral water and packaged drinking water producers need moulds that produce lightweight, strong, visually appealing bottles at maximum output speed. Our water bottle mould designs are optimised for:

• 250ml water bottle mould: Single-serve — hotels, airlines, events. PCO 1881 neck. 8.5–10g preform weight.
• 500ml water bottle mould: Most popular SKU in India. Available in 1, 2, and 4-cavity. 10–13g preform.
• 1 litre water bottle mould: Home and office segment. 18–22g preform. 2-cavity most common.
• 2 litre water bottle mould: Family pack. Requires specific blow ratio for even wall distribution.
• 5 litre water bottle mould: Bulk / refill segment. Handle mould optional.
• 20 litre jar mould (HDPE): Water dispenser jars. Heavy-duty HDPE extrusion blow mould.

PET Bottle Mould Design Process — Step by Step

• Step 1 — Bottle brief: Share your bottle dimensions, volume, neck size, weight target, and machine model
• Step 2 — Design review: Our engineer reviews your 3D file or creates a design proposal based on your brief
• Step 3 — Design approval: 3D mould design shared with you for approval before machining begins
• Step 4 — CNC machining: Mould machined in-house at Vatva GIDC — ±0.01mm tolerance
• Step 5 — Trial run: Mould trial-run on our facility machine — bottle samples sent for your approval
• Step 6 — Dispatch: Mould dispatched with full quality documentation

Custom PET Bottle Mould Design — All Industries
